AXIS D2123-VE Radar sort

The AXIS D2123-VE is a network security radar designed for outdoor perimeter detection. Utilizing FMCW radar technology at 60 GHz, it reliably detects and classifies humans and vehicles up to 90 meters away. Its compact, vandal-resistant housing (IP66/IP67, IK08) ensures robust performance in harsh environments.

Advantages

Reliable detection in all weather conditions, low false alarm rate, easy integration with Axis PTZ cameras and VMS, and PoE-powered for simple installation.

Suitable for

• Perimeter security for industrial sites, warehouses, and critical infrastructure
• Outdoor surveillance in challenging environments
• Integration with existing Axis video management systems

Key specifications

• Detection Technology: FMCW Radar
• Frequency Band: 60 GHz
• Max Detection Range (Human): 60 m (197 ft)
• Max Detection Range (Vehicle): 90 m (295 ft)
• Horizontal Detection Angle: 90°
• Vertical Detection Angle: 15°
• Power over Ethernet (PoE): PoE Class 3 (IEEE 802.3af/at Type 1 Class 3)
• Max Power Consumption: 12.95 W
• Network Interface: 1x RJ45 10/100 Mbps Ethernet
• Ingress Protection (IP Rating): IP66, IP67
• Vandal Resistance (IK Rating): IK08
• Operating Temperature: -40 °C to 60 °C (-40 °F to 140 °F)
• Alarm Inputs/Outputs: 2x configurable supervised inputs, 2x configurable digital outputs
• Object Classification: Human, Vehicle
• Mounting Options: Wall, pole, or ceiling mount (accessories required)
• Color: Black
• Security Features: Signed firmware, secure boot, password protection, HTTPS encryption
• VMS Compatibility: Axis Camera Station, ONVIF Profile G/S/T

Recommendations

For optimal performance, pair with Axis PTZ cameras for automated tracking. Use Axis mounting accessories for secure installation.
