Chief CPAE080 projektorholder tilbehør sort

The NEC CMA080 Black is an external cable management column designed for tidy and serviceable monitor installations. It provides an inlay-style channel that keeps cables concealed along monitor mounts or stands, with a black finish that matches NEC monitors and many mounting solutions. The column is supplied in pre-cut lengths and can be shortened or re-drilled to fit custom installations.

Advantages

Quick Service external cable management eliminates the need to pre-route cables, allowing cables to be installed or removed without disassembling the mount. The inlay style offers easy serviceability, and the column can be cut to length or re-drilled for custom configurations. Grooves on the outer surface give a neat aesthetic and act as drill guides. Pre-cut options (80, 150 and 300 cm) include three pre-drilled thru holes at each end for straightforward mounting.

Suitable for

• Cable management for single or multiple monitor mounts
• Office and corporate installations requiring tidy cable routing
• AV racks and presentation stands where serviceability is needed
• Custom installations that require cutting or re-drilling the column

Key specifications

• Brand: NEC
• Model: CMA080
• Colour: Black
• Available pre-cut lengths: 80 cm, 150 cm, 300 cm
• Pre-drilled: 3 thru holes in each column end
• Features: Inlay-style channel, grooved outer surface, cut-to-length and re-drillable
• MPN: 100013607
• EAN: 841872158129

How to use

Position the NEC CMA080 column alongside the monitor mount or stand and route cables into the inlay channel. If the pre-cut length is too long, measure and cut the column to the required size, then deburr the cut edge. Use the grooves as guides when drilling additional holes; align and fasten the column using the pre-drilled thru holes or newly drilled holes to secure it to the mount or surface. Cables can be added or removed from the inlay channel without disassembling the mount for maintenance or reconfiguration.

Recommendations

For best results, verify the required length before cutting and use appropriate cutting and deburring tools. When drilling, follow the grooves to maintain alignment and protect internal cables. Ensure screws and fasteners are compatible with your mount and do not compress or damage routed cables.
