Intern WLAN/Bluetooth-adapter Intel Wi-Fi 7 BE201

The Internal WLAN/Bluetooth Adapter Intel Wi-Fi 7 BE201 is a compact M.2 card that supports the new Wi‑Fi 7 standard (IEEE 802.11be) and Bluetooth connectivity. It operates on tri‑band frequencies (2.4 GHz / 5 GHz / 5 GHz) with a 2x2 antenna configuration and a maximum data transfer rate up to 5000 Mbit/s, providing high throughput for demanding wireless applications. The card is compatible with multiple IEEE 802.11 standards and connects via an M.2 host interface.

Advantages

The Intel Wi‑Fi 7 BE201 delivers increased spectral efficiency and simultaneous multi‑user access through modern wireless technologies, enabling robust, low‑latency connections. Its compact M.2 form factor and broad standard support ensure easy integration into compatible laptops and desktop motherboards while supporting high wireless data rates and Bluetooth functionality.

Suitable for

• High‑speed wireless networking and streaming
• Online gaming and low‑latency applications
• Software development and testing requiring fast wireless links
• Upgrading compatible laptops or mini‑PCs to Wi‑Fi 7 and Bluetooth

Key specifications

• Model: Intel Wi‑Fi 7 BE201 (MPN: BE201.NGWG)
• Form factor / Host interface: M.2
• Wireless standard: IEEE 802.11be (Wi‑Fi 7), backward compatible with IEEE 802.11a/b/g/n/ac/ax and others
• Frequency bands: Tri‑band 2.4 GHz / 5 GHz / 5 GHz
• Antenna configuration: 2x2
• Maximum data transfer rate: 5000 Mbit/s
• Connectivity: WLAN and Bluetooth
• Weight: 0.0031 kg
• EAN: 0675902056211

How to use

Install the Intel Wi‑Fi 7 BE201 into a compatible M.2 slot on your laptop or desktop motherboard following the device manufacturer’s instructions. After physical installation, install or update the appropriate Intel drivers for your operating system to enable WLAN and Bluetooth functionality. Configure network settings through your operating system’s network manager to connect to available wireless networks.

Recommendations

For optimal performance, use the adapter with a system that supports M.2 WLAN modules and updated BIOS/firmware. Position external antennas or use devices with integrated antenna paths designed for M.2 cards to maximize signal quality. Keep drivers and firmware up to date to benefit from stability and performance improvements.
