Netværkskort Digitus DN-10110 Gigabit Ethernet PCI

The Digitus DN-10110 Gigabit Ethernet PCI network card provides wired connectivity for desktop systems, offering up to 1000 Mbit/s transfer rates over existing network cabling. It installs into a PCI slot and includes a low-profile bracket for compact builds, using the RTL8169SC chipset to support standard Ethernet networking protocols.

Advantages

This Gigabit Ethernet PCI card adds an extra Ethernet port to a PC, enables data transfer rates of 10/100/1000 Mbps, and comes with a space-saving low-profile plate for small form-factor cases. The card is compatible with common IEEE 802.3 standards and is suitable for upgrading older systems to faster wired networking.

Suitable for

• Upgrading a desktop PC to Gigabit wired network
• Adding an extra Ethernet port to a system
• Small form-factor or low-profile desktop builds

Key specifications

• Brand: DIGITUS
• Model: DN-10110
• Interface: PCI host interface
• Connectivity technology: Wired Ethernet
• Maximum data transfer rate: 1000 Mbit/s (Gigabit Ethernet)
• Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
• Chipset: RTL8169SC
• Form factor: 32-bit, low-profile bracket
• EAN: 4016032310778

How to use

Power off the computer and open the case. Insert the DN-10110 into an available PCI slot and secure the low-profile bracket to the case. Close the case and power on the system. Install any required drivers provided by the operating system or supplied by the manufacturer. Connect an Ethernet cable to the card’s RJ45 port and to your network switch or router to begin using wired network services.

Recommendations

Install the card in a properly grounded PC, use a quality Cat5e or Cat6 cable for Gigabit speeds, and ensure drivers are up to date for optimal performance.
