Udendørspanel BCS-PAN-C2-N

Capture every visitor in crisp 1080p Full HD with the BCS-PAN-C2-N outdoor panel, featuring a 120° wide-angle lens that leaves no blind spots at your entrance. Its IK07-rated aluminum alloy faceplate and IP65 weather sealing shrug off vandalism, dust, and rain, while PoE support simplifies installation with a single cable for both data and power.

Overview

The BCS-PAN-C2-N is a surface-mount external panel designed for BCS Line IP intercom systems. It combines a physical call button, two-way audio with built-in microphone and speaker, and a relay output for electric strike control, enabling both visitor communication and door release from one compact unit. Night vision via IR LED illumination ensures clear images even in complete darkness, and H.264 compression keeps network bandwidth efficient.

What stands out

• 2MP Full HD camera with 120° horizontal viewing angle for wide coverage
• Two-way audio with echo-free microphone and speaker
• PoE (802.3af) or 12V DC power options for flexible installation
• Integrated relay output to trigger electric strikes or magnetic locks
• Vandal-resistant IK07 aluminum alloy housing with IP65 ingress protection
• IR night vision for 24/7 visibility
• Single physical call button with status feedback
• H.264 video compression for efficient streaming and storage

Technical details

• Camera: 2 Megapixel (1920x1080) CMOS, wide-angle lens
• Viewing angle: 120° horizontal
• Audio: Two-way, built-in microphone and speaker
• Connectivity: 1x RJ-45 10/100 Mbps Ethernet
• Power: PoE (802.3af) or 12V DC
• Relay output: 1x for electric strike/magnetic lock
• Material: Aluminum alloy
• Ingress protection: IP65
• Vandal resistance: IK07
• Operating temperature: -30°C to +60°C
• Colour: Silver/Grey
• Compatibility: BCS Line IP intercom systems

Our verdict

The BCS-PAN-C2-N is a robust and feature-rich outdoor intercom panel that delivers clear video, reliable two-way audio, and convenient door control in a weatherproof, vandal-resistant package. Ideal for residential or small business entrances where durability and ease of installation are paramount.
