DIGITUS OnLine UPS-modul 2000VA / 2000W

DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
DIGITUS OnLine UPS-modul 2000VA / 2000W
3.840,80 kr.
The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.- High efficiency in online mode, higher ... Læs mere
Lagerstatus 1 Produktkode 300091 Mærke DIGITUS Model DN-170095 Garanti 2 år
KategoriOnline UPS

Levering & returnering

Forventet levering fredag den 6. november
Du holdes opdateret via vores detaljerede sporingssystem
Betalingsmuligheder
BetalingskortVisaMastercardPayPalApple PayGoogle PayBankoverførsel

Beskrivelse

The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.

- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.
- High efficiency in online mode, higher efficiency means optimized energy management and lower heat dissipation, resulting in energy savings and improved reliability.
- User-friendly LCD screen provides insight into UPS status for easy installation, configuration and operation.
- Compact rack/tower design optimizes the installation space in the rack and enables flexible installation.
- Minimize device downtime with hot-swappable, user-replaceable battery modules that can be replaced during operation.
- External battery modules allow the runtime to be extended.
- High number of outlets (8 x C13) for optimum power distribution to the consumers.
- Various communication interfaces (RS232/USB, parallel port, SNMP slot) enable remote monitoring of the system.
- Automatic battery self-test and fan speed control increase the service life of the components.
- The REPO function (Remote Emergency Power Off) switches the UPS off in the event of an emergency. If an emergency occurs, the REPO switch turns off the rectifier and the inverter and immediately stops the power supply to the load. The UPS stops charging.

The DIGITUS® OnLine UPS is a double-conversion UPS solution that offers first-class power failure protection and continuous power generation in a compact and flexible system. The single-phase UPS operates with high energy efficiency and is ideal for protecting critical infrastructure in both centralized and edge network applications. Scalable runtime options with matching external battery cabinets provide additional flexibility when a longer uninterruptible power supply is required. The user-friendly LCD display and network management capability, including configuration, make this system easy to install and maintain. With market-leading efficiency and unity power factor, the UPS meets your critical application requirements.

Vigtigste egenskaber
  • Online double conversion system (VFI-SS-111)
  • Input: IEC60320 C20 socket, 208/220/230/240 Vac
  • Output: 8 x IEC60320 C13, max. 10A per socket outlet
  • Nominal system power: 2000 VA / 2000 W, power factor 1.0
  • AC-AC (online VFI) efficiency: 93 %, ECO mode efficiency: 98 %.
  • Internal battery pack can be replaced during operation.
  • Battery: Valve-protected, non-spillable lead-acid battery
  • Battery quantity: 4 x 12V x 9.0 Ah
  • Charging: 4 hours to 90% capacity after full discharge
  • Network connection: Optional SNMP/Webcard (part number DN-170100) enables the UPS to be monitored remotely.
  • Local communication ports: USB, RS-232 (serial), SNMP card (optional), relay card (optional)
  • Emergency Power-off (EPO) contact for switching off the UPS in an emergency
  • Maximum operating temperature: 0 - 40 °C
  • Storage temperature: -25 - 55 °C
  • Relative humidity: 20 - 90% non-condensing
  • Operating altitude: < 1500 m
  • Product dimensions WxDxH (mm): 440 (19") x 460 x 86.5 (2U)
  • Product weight: 19.5 kg
  • Shipping dimensions WxDxH (mm): 560 x 590 x 200
  • Shipping weight: 23.7 kg
  • Safety standards: IEC/EN62040-1,IEC/EN60950-1
  • EMC standards: IEC/EN62040-2,IEC61000-4-2,IEC61000-4-3,IEC61000-4-4, IEC61000-4-5,IEC61000-4-6,IEC61000-4-8
  • Optionally available: 19" UPS mounting kit (profile rails), article number DN-170109
  • IP protection class: IP21
  • Heat dissipation: 614 BTU/h
  • Noise level in online mode: approx. 50 dB(A) at a distance of 1 m (may vary slightly depending on load and ambient temperature).

Specifikationer

Specifikationer
Aftageligt strømkabel
Ja
Antal AC-udgange
8 AC outlet(s)
Antal serielle porte
1
Antal understøttede batterier
4
Batterikapacitet
9 Ah
Batterispænding
12 V
Bredde
440 mm
Driftshøjde
0 - 1500 m
Driftsindgangsspænding (maks.)
240 V
Driftsindgangsspænding (min.)
208 V
Driftstemperatur (T-T)
0 - 40 °C
Dybde
460 mm
Effektfaktor
1
Effektivitet
93%
Effektivitet (ECO-tilstand)
98%
Emballagedybde
595 mm
Ethernet LAN (RJ-45)-porte
2
Formfaktor
Rackmonteret
Højde
86.5 mm
Indbygget blæser
Ja
Kølingstype
Aktiv
Maks. strøm
10 A
Manual
Ja
Medfølgende kabler
RS-232, USB cable
Opbevaringstemperatur (T-T)
-25 - 55 °C
Opladningstid for batteri (90 %)
4 h
Oprindelsesland
Kina
Pakkehøjde
200 mm
Pakkens bredde
555 mm
Pakkens vægt
22.9 kg
Pakkevolumen
66705.5 cm³
Produktfarve
Sort
Rackmonteringssæt
Ja
Relativ luftfugtighed under drift (H-H)
20 - 90%
Relativ luftfugtighed ved opbevaring (H-H)
20 - 90%
Seriel interface
RS-232
Skærmtype
LCD
Strømkildetype
AC
Strømstik
C20 coupler
Størrelse (tommer)
48.3 cm (19")
Tilslutning til nødafbryder (EPO)
Ja
Typer af stikkontakter
C13 coupler
Udgangseffekt
2000 W
Udgangseffektkapacitet
1.5 kVA
UK-toldtarifkode
85044085
UPS-topologi
Dobbeltkonvertering (online)
USB-port
Ja
USB-stiktype
USB Type-B
Vægt
19.5 kg

Brochure

Åbn Brochure
Prishistorik for de seneste 6 måneder
DIGITUS OnLine UPS-modul 2000VA / 2000W
Aktuel
3.840,80 kr.
Laveste
3.814,15 kr.
Højeste
4.203,24 kr.
Ændring 24 timer
+0,43 kr.   +0%
Uge
-8,97 kr.   0%
Måned
-12,67 kr.   0%
