GIRA 099600 effektdiode, 1 stk.

The GIRA 099600 is a silicon power diode engineered for rectification and reverse-current protection in building installations. Its axial-leaded package and 1.5 A average forward current make it suitable for dimmers, control units, and general-purpose DC circuits where a compact, through-hole component is required.

Highlights

• Silicon rectifier diode with unidirectional polarity
• Peak reverse voltage of 1000 V for robust blocking
• Axial leaded package for through-hole mounting
• Supplied as a single piece

In daily use

Installers value the 099600 for decoupling and freewheeling tasks in Gira control gear. Its 1.1 V forward drop at rated current keeps losses low, while the 50 A surge capability handles inrush events. The diode operates from -55 °C to +150 °C, covering demanding enclosure conditions.

Full specifications

• Product type: Diode
• Diode type: Power diode / rectifier diode
• Function: Rectification, decoupling, reverse current protection
• Mounting type: Through-hole
• Package type: Axial leaded diode
• Number of terminals: 2
• Polarity: Unidirectional
• Material: Silicon
• Maximum average forward current (If(AV)): 1.5 A
• Maximum peak reverse voltage (Vrrm): 1000 V
• Maximum forward voltage drop (Vf): 1.1 V @ 1.5 A
• Maximum reverse current (Ir): 5 µA @ 1000 V
• Maximum non-repetitive peak surge current (Ifsm): 50 A
• Operating temperature range: -55 °C to +150 °C
• Quantity per pack: 1 piece

Final note

A reliable rectifier diode for Gira installation electronics, supplied individually for service and repair.
